Empisal EES10 - Zipper insertion; Centered zipper installation

27
Zipper insertion
3.5 1.5~3.0
Attention: Zipper foot should be used f or
sewing width center needle position s traight
stitch only. It is possible that needle could
hit the presser foot and break when sewing
other patterns.
5mm
Inserting a centered zipper
- Baste the zipper opening on the garment.
- Press open the seam allowance. Place the
zipper face down on the seam allowance with
the teeth against the seam line. Baste the zipper
tape.
- Attach the zipper foot. Attach the right side of
the presser foot pin to the holder when sewing
the left side of the zipper.
- Attach the left side of the presser foot pin to the
presser foot holder when sewing the right side
of the zipper.
- Stitch left side of the zipper from top to bottom.
- Stitch across the lower end and right side of
zipper. Remove the basting and press.
