EMS AIRFLOW Prophylaxis Master User Manual

ENGLISH
FB-618/AU – rev.E – ed.2019/08
18/48
PIEZON
®
power setting
The unit is equipped with NO PAIN
®
technology which provides an adaptive response in function
according to the load applied to the instrument.
The following table shows the maximum output power as per user power setting:
PIEZON
®
Power
Power Setting
0
1
2
3
4
5
6
7
8
9
10
Max Output Power [W]
0 0.4 1.2 2.1 3.0 3.9 4.8 5.6 6.4 7.2 8.0
Risk of tip breakage: with ENDO files, do not exceed 2.5W (power setting “3” max.)
AIRFLOW
®
pressure setting
Both the PLUS and CLASSIC powder chambers have an integrated dynamic pressure regulator
that automatically set the optimal pressure range for the selected powder chamber and related
powder type as detailed in chapter “Powder Chambers”.
The following table shows the static and approximate dynamic pressures
3
as per selected powder
chamber and user power setting:
AIRFLOW
®
Pressure
Pressure Setting
0
1
2
3
4
5
6
7
8
9
10
Static [Bar]
/ 2.5 2.7 3.0 3.2 3.5 3.7 4.0 4.2 4.5 4.7
CLASSIC dynamic [Bar]
/ 1.9 2.1 2.3 2.6 2.8 3.0 3.2 3.5 3.7 3.9
PLUS dynamic [Bar]
/ 1.5 1.7 1.9 2.0 2.2 2.4 2.6 2.7 2.9 3.1
3
Dynamic pressures depend on handpiece and powder type too. The listed pressures are for information
purpose and referring to the commonly used EL-308 AIRFLOW
®
Handpiece with DV-082 and DV-048
powders.

EMS AIRFLOW Prophylaxis Master Specifications

General

Water Flow Rate	Adjustable
Powder Flow Rate	Adjustable
Technology	AIRFLOW, PERIOFLOW, PIEZON
Water Supply	Integrated water tank
Control	Foot control
Handpieces	AIRFLOW, PERIOFLOW, PIEZON
Water tank capacity	Approx. 800 ml
Water pressure	1 - 5 bar (100 - 500 kPa)
Operating mode	Continuous
Type	Air polishing system
Powder Type	Erythritol, Glycine
Nozzle Types	Standard, Perio
Power Supply	100-240 V, 50/60 Hz
