Operation Deltabar S FOUNDATION Fieldbus
20 Endress+Hauser
5.3.4 Taking pressure applied at device as value
Example: performing position adjustment.
Onsite display Operation
P01-xxxxxxxx-19-xx-xx-en-158
The bottom line on the onsite display displays the pressure
present, here 3.9 mbar.
P01-xxxxxxxx-19-xx-xx-en-159
Use "+" or "–" to switch to the "Confirm" option. The
active selection is highlighted in black.
P01-xxxxxxxx-19-xx-xx-en-037
Use "E" to assign the value (3.9 mbar) to the POS. ZERO
ADJUST parameter. The device confirms the calibration
and jumps back to the parameter, here POS. ZERO
ADJUST (see next graphic).
P01-xxxxxxxx-19-xx-xx-en-160
Switch to the next parameter with "E".
