Product identification Deltabar S FOUNDATION Fieldbus
4 Endress+Hauser
1.5 Safety icons
2 Product identification
The following options are available for identification of the measuring device:
• Nameplate specifications
• Order code with breakdown of the device features on the delivery note
• Enter serial numbers from nameplates in W@M Device Viewer
(www.endress.com/deviceviewer): All information about the measuring device is displayed.
For an overview of the technical documentation provided, enter the serial number from the
nameplates in the W@M Device Viewer (www.endress.com/deviceviewer).
3 Installation
3.1 General installation instructions
#
Warning!
The seal is not allowed to press on the process isolating diaphragm as this could affect the
measurement result.
!
Note!
• Due to the orientation of the Deltabar S, there may be a shift in the measured value, i.e. when
the container is empty, the measured value does not display zero. You can correct this zero
point shift either via the "zero" key on the electronic insert, or on the outside of the device or
via the onsite display. See Page 15, Section 5.2.1 "Position of operating elements", Page 16,
Section 5.2.2 "Function of the operating elements – onsite display not connected" and Page
25, Section 6.3 "Position adjustment".
• For FMD77 and FMD78, please refer to Section 3.3 "Installation instructions for devices with
diaphragm seals (FMD78)", Page 7.
• The FMD77 must only be insulated up to a certain height.
Symbol Meaning
#
Warning!
A warning highlights actions or procedures which, if not performed correctly, will lead to personal injury,
a safety hazard or destruction of the instrument.
"
Caution!
Caution highlights actions or procedures which, if not performed correctly, may lead to personal injury or
incorrect functioning of the instrument.
!
Note!
A note highlights actions or procedures which, if not performed correctly, may indirectly affect operation
or may lead to an instrument response which is not planned.
