Endress+Hauser Deltabar S PMD70 User Manual

Commissioning Deltabar S FOUNDATION Fieldbus
42 Endress+Hauser
!
Note!
For onsite operation, see also Page 16, Section 5.2.3 "Function of the operating elements –
onsite display connected" and Page 17, Section 5.3 "Onsite operation via onsite display".
6.7 Scaling the OUT parameter
In the Analog Input Block, the input value or input range can be scaled in accordance with the
automation requirements.
Example:
The measuring range 0 to 500 mbar should be rescaled to 0 to 100 %.
• Select XD_SCALE group.
– For EU_0, enter "0".
– For EU_100, enter "500".
– For UNITS_INDEX, enter "mbar".
• Select OUT_SCALE group.
– For EU_0, enter "0".
– For EU_100, enter "10000".
– For UNITS_INDEX, select "%" for example.
The unit selected here does not have any effect on the scaling. This unit is not displayed on
the onsite display or in the operating program such as FieldCare.
• Result:
Onsite operation FieldCare
Measured value display
Switch from the measured value display to GROUP
SELECTION with F.
Measured value display
Select QUICK SETUP menu.
GROUP SELECTION
Select MEASURING MODE.
Measuring Mode
Select the Primary Value Type parameter.
MEASURING MODE
Select "Pressure" option.
Primary Value Type
Select "Pressure" option.
GROUP SELECTION
Select QUICK SETUP menu.
POS. ZERO ADJUST
Due to orientation of the device, there may be a shift in the
measured value. You correct the MEASURED VALUE via the
POS. ZERO ADJUST parameter with the "Confirm" option,
i. e. you assign the value 0.0 to the pressure present.
POS. ZERO ADJUST
Due to orientation of the device, there may be a shift in the
measured value. You correct the MEASURED VALUE via the
POS. ZERO ADJUST parameter with the "Confirm" option,
i. e. you assign the value 0.0 to the pressure present.
DAMPING TIME
Enter damping time (time constant ). The damping affects
the speed at which all subsequent elements, such as the
onsite display, measured value and OUT value of the Analog
Input Block react to a change in the pressure.
DAMPING TIME
Enter damping time (time constant ). The damping affects
the speed at which all subsequent elements, such as the
onsite display, measured value and OUT value of the Analog
Input Block react to a change in the pressure.
