Identification Levelflex M FMP40 FOUNDATION Fieldbus
8 Endress+Hauser
CTM DN100 PN25/40, AlloyC22 >316L flange EN1092-1 (DIN2527)
CWJ DN150 PN10/16 B1, 316L flange EN1092-1 (DIN2527 C)
CWM DN150 PN10/16, AlloyC22 >316L flange EN1092-1 (DIN2527)
CXJ DN200 PN16 B1, 316L flange EN1092-1 (DIN2527 C)
CRJ Thread ISO228 G3/4, 316L
GRJ Thread ISO228 G1-1/2, 316L
GRM Thread ISO228 G1-1/2, AlloyC22
CNJ Thread ANSI NPT3/4, 316L
GNJ Thread ANSI NPT1-1/2, 316L
GNM Thread ANSI NPT1-1/2, AlloyC22
KDJ 10K 40A RF, 316L flange JIS B2220
KDM 10K 40A, AlloyC22 >316L flange JIS B2220
KEJ 10K 50A RF, 316L flange JIS B2220
KEM 10K 50A, AlloyC22 >316L flange JIS B2220
KLJ 10K 80A RF, 316L flange JIS B2220
KLM 10K 80A, AlloyC22 >316L flange JIS B2220
KPJ 10K 100A RF, 316L flange JIS B2220
KPM 10K 100A, AlloyC22 >316L flange JIS B2220
YY9 Special version, TSP-No. to be spec.
60 Power Supply; Output:
B 2-wire; 4-20mA SIL HART
D2-wire; PROFIBUS PA
F 2-wire; FOUNDATION Fieldbus
K 2-wire; 4-20mA HART, Interface measurement
G 4-wire 90-250VAC; 4-20mA SIL HART
H 4-wire 10.5-32VDC; 4-20mA SIL HART
Y Special version, TSP-No. to be spec.
70 Operation:
1 W/o display, via communication
2 4-line display VU331, Envelope curve display on site
3 Prepared for FHX40, Remote display (Accessory)
9 Special version, TSP-No. to be spec.
80 Type of Probe:
B Compact, centering disk d=45mm, 316L, pipe diameter DN50/2"
C Compact, centering disk d=75mm, 316L, pipe diameter DN80/3" + DN100/4"
D Spacer, center rod d=45mm, 316L, pipe diameter DN50/2", spacer, 400mm
E Spacer, center rod d=75mm, 316L,pipe diameter DN80/3" + DN100/4",
spacer,400mm
F Remote, cable 3m, top, center d=45mm, centering disk d=45mm, 316L
pipe diameter DN50/2", 316L
G Remote, cable 3m, top, center d=75mm, centering disk d=75mm, 316L,
pipe diameter DN80/3" + DN100/4", 316L
H Remote, cable 3m, side, center d=45mm, centering disk d=45mm, 316L,
pipe diameter DN50/2"
I Remote, cable 3m, side, center d=75mm, centering disk d=75mm, 316L,
pipe diameter DN80/3" + DN100/4"
1 Compact, basic version
2 Spacer, 400mm
3 Remote, cable 3m, top entry
4 Remote, cable 3m, side entry
9 Special version, TSP-No. to be spec.
90 Housing; Cable Entry:
A F12 Alu, coated IP68; gland M20
B F12 Alu, coated IP68; thread G1/2
C F12 Alu, coated IP68; thread NPT1/2
D F12 Alu, coated IP68; plug M12
E F12 Alu, coated IP68; plug 7/8"
G T12 Alu, coated IP68; gland M20 (Ex d > thread M20)
H T12 Alu, coated IP68; thread G1/2
J T12 Alu, coated IP68; thread NPT1/2
K T12 Alu, coated IP68; plug M12
L T12 Alu, coated IP68; plug 7/8"
M T12 Alu, coated IP68; gland M20 + OVP
1)
N T12 Alu, coated IP68; thread G1/2 + OVP
1)
P T12 Alu, coated IP68; thread NPT1/2+OVP
1)
Q T12 Alu, coated IP68; plug M12 + OVP
1)
R T12 Alu, coated IP68; plug 7/8" + OVP
1)
50 Process Connection:
