Endress+Hauser Proline Prosonic Flow 93 Brief Operating Instructions

Proline Prosonic Flow 93 Installation
Endress+Hauser
13
Running the Quick Setup for Clamp-on type of mounting
• Only the steps necessary for the type of mounting (Clamp-on) are described.
• Enter or select installation-specific values or the values specified here.
• Read off the installation distances necessary for mounting.
Home position

Quick Setup

Setup sensor

Language
CH1  Channel
Clamp-on  Measurement
Sensor type
1 or 2  Sensor configuration = Number of traverses
Pipe standard
Nominal diameter
Pipe material
Sound velocity pipe
Pipe diameter
Circumference
Wall thickness
Liner Material
Sound Velocity Liner
Liner Thickness
Liquid Installation
distances for
measurement via
one traverse:
Installation
distances for
measurement via
two traverses:
Temperature
Sound velocity liquid
Position sensor  –
Wire length  –
Sensor distance 
No  Other measurement?
No  Other channel?

Setup sensor
