Digital Video Recorder
V1.3
75
Specifications
VIDEO
Signal Format NTSC or PAL (Auto Detect)
Video Input Composite: 8 or 16 looping inputs, 1 Vp-p, auto-terminating, 75 Ohms
Monitor Outputs
Composite: 1 BNC, 1 Vp-p, 75 Ohms
SPOT: 1 BNC, 1 Vp-p, 75 Ohms
VGA: 1
Video Resolution
Composite: 720x480 (NTSC), 720x576 (PAL)
VGA: 800x600, 1024x768, 1280x1024 @ 60Hz
Record Speed
(images per second)
Real-time: 480ips (NTSC), 400ips (PAL) @ CIF (16-ch Model)
Real-time: 240ips (NTSC), 200ips (PAL) @ Half D1 (8-ch Model)
Playback Speed
(images per second)
Full Duplex: 480ips (NTSC), 400ips (PAL) @ CIF (16-ch Model)
Full Duplex: 240ips (NTSC), 200ips (PAL) @ Half D1 (8-ch Model)
INPUTS/OUTPUTS
Alarm Input
8 or 16 terminal, programmable as NC or NO, 2.4V (NC) or 0.3V (NO) threshold,
5VDC
Alarm Output 2 relay output, programmable as NC or NO, 2A@125VAC, 1A@30VDC
Alarm Reset Input 1 TTL, terminal block
Internal Buzzer 80dB at 10cm
Network Connectivity 10/100 Mbps Ethernet (RJ-45)
Text Input POS Interface, ATM Interface
CONNECTORS
Video Input Composite: 8 or 16 BNC
Video Loop Composite: 8 or 16 BNC (Auto Terminating)
Monitor Output
Composite: 1 BNC
VGA: 1 VGA
SPOT (Composite): 1 BNC
Alarm Input/Output Terminal Blocks
Ethernet Port RJ-45
RS232C Serial Port DB9 (P)
RS485 Serial Port Two-connector terminal block
IR Port 1 Remote Control
USB Port 2 (USB 2.0)
STORAGE
Primary Storage SATA hard disk drive (up to 4) (up to 3 with an internal DVD RW drive)
Secondary Storage*
Built-in DVD RW drive
USB hard disk drive or flash drive
GENERAL
Dimensions (W x H x D) 430mm x 88mm x 405mm
Unit Weight 7.6kg
Shipping Weight 11.9kg
Shipping Dimensions
(W x H x D)
540mm x 290mm x 590mm
Operating Temperature 5°C to 40°C
Operating Humidity 0% to 90%
Power 100 to 240 VAC, 1.2 – 0.6 A, 60/50Hz
Power Consumption Max. 45W
Approvals FCC, UL**, CB, CE
* When installing an internal DVD RW drive, connect the SATA I/O cable to the SATA3 socket.
** CAUTION: Risk of Explosion if Battery is replaced by an Incorrect Type. Dispose of Used Batteries According to the Instructions. This equipment
is indoor use and all the communication wiring are limited to inside of the building.
Specifications are subject to change without notice.
