Modbus Integrator's Guide for the Cordex® CXC HP Controller | 3 - Using Modbus
Table 3-8 Counters data points
Name Register Format
Down Counter: Input 02:Input Status Boolean
Up Counter: Input 02:Input Status Boolean
Down Counter: Output 04:Input Register 32-bit Floating Point
Up Counter: Output 04:Input Register 32-bit Floating Point
Table 3-9 User alarms data points
Name Register Format
Threshold User Alarm/835: User-
Defined
02:Input Status Boolean
Digital User Alarm/547: User-De-
fined
02:Input Status Boolean
Table 3-10 Cordex® CXC HP L-ADIO data points
Name Register Format
K1 01:Coil Status Boolean
K2 01:Coil Status Boolean
K3 01:Coil Status Boolean
K4 01:Coil Status Boolean
K5 01:Coil Status Boolean
K6 01:Coil Status Boolean
K7 01:Coil Status Boolean
K8 01:Coil Status Boolean
K9 01:Coil Status Boolean
K10 01:Coil Status Boolean
K11 01:Coil Status Boolean
K12 01:Coil Status Boolean
D1 02:Input Status Boolean
