Modbus Integrator's Guide for the Cordex® CXC HP Controller | 3 - Using Modbus
Table 3-24 DC System Polarium battery data points (continued)
Name Register Format
Power 04:Input Register 32-bit Floating Point
Battery Mode 04:Input Register 32-bit Floating Point
This value corresponds to the
mode of the battery as follows:
• Unknown = 0
• NoBattery = 1
• Discharging = 3
• Charging = 5
• Float = 10
Battery Capacity Rating 04:Input Register 32-bit Floating Point
Active Temperature 04:Input Register 32-bit Floating Point
Minimum Temperature 04:Input Register 32-bit Floating Point
Maximum Temperature 04:Input Register 32-bit Floating Point
Breaker/Fuse 04:Input Register 32-bit Floating Point
This value corresponds to the com-
bined status of the breakers of all
the batteries in the system, as fol-
lows:
• All breakers closed = 0
• One or more breakers open
= 1
Table 3-25 DC system loads data points
Name Register Format
Inverter System Load: Load Volt-
age High
02:Input Status Boolean
Inverter System Load: Load Cur-
rent High
02:Input Status Boolean
Inverter System Load: Load Break-
er/Fuse Open
02:Input Status Boolean
Inverter System Load: Load Volt-
age Low
02:Input Status Boolean
0350114-J0 Rev N Page 31
