Modbus Integrator's Guide for the Cordex® CXC HP Controller | 3 - Using Modbus
Table 3-14 PSU ADIO data points (continued)
Name Register Format
K4 01:Coil Status Boolean
K5 01:Coil Status Boolean
D1 02:Input Status Boolean
D2 02:Input Status Boolean
Temperature Sensor #1 Failure 02:Input Status Boolean
Temperature Sensor #2 Failure 02:Input Status Boolean
CAN Serial Number 04:Input Register 32-bit Integer
V1 04:Input Register 32-bit Floating Point
V2 04:Input Register 32-bit Floating Point
T1 04:Input Register 32-bit Floating Point
T2 04:Input Register 32-bit Floating Point
I1 04:Input Register 32-bit Floating Point
Table 3-15 Shunt Mux ADIO data points
Name Register Format
CAN Serial Number 04:Input Register 32-bit Integer
I1 04:Input Register 32-bit Floating Point
I2 04:Input Register 32-bit Floating Point
I3 04:Input Register 32-bit Floating Point
I4 04:Input Register 32-bit Floating Point
I5 04:Input Register 32-bit Floating Point
I6 04:Input Register 32-bit Floating Point
I7 04:Input Register 32-bit Floating Point
I8 04:Input Register 32-bit Floating Point
I9 04:Input Register 32-bit Floating Point
I10 04:Input Register 32-bit Floating Point
I11 04:Input Register 32-bit Floating Point
I12 04:Input Register 32-bit Floating Point
Page 20 0350114-J0 Rev N
