Modbus Integrator's Guide for the Cordex® CXC HP Controller | 3 - Using Modbus
Table 3-25 DC system loads data points (continued)
Name Register Format
Load: Load Voltage High 02:Input Status Boolean
Load: Load Current High 02:Input Status Boolean
Load: Load Breaker/Fuse Open 02:Input Status Boolean
Load: Load Voltage Low 02:Input Status Boolean
Inverter System Load: Current 04:Input Register 32-bit Floating Point
Ref. Load: Current 04:Input Register 32-bit Floating Point
Load: Current 04:Input Register 32-bit Floating Point
An example of each type of load is given in the table: Inverter System Load, Load, and Referenced Load
(Ref. Load)
Table 3-26 DC system disconnects data points
Name Register Format
Disconnect: Disconnect Inhibit 02:Input Status Boolean
Disconnect: Disconnect Pending 02:Input Status Boolean
Disconnect: Disconnect Active 02:Input Status Boolean
Disconnect: Disconnect Open 02:Input Status Boolean
Disconnect: Manually Closed 02:Input Status Boolean
Disconnect: Manually Open 02:Input Status Boolean
Disconnect: Contactor State Error 02:Input Status Boolean
Table 3-27 DC system shunts data point
Name Register Format
Shunt/348: Current 04:Input Register 32-bit Floating Point
Page 32 0350114-J0 Rev N
