Modbus Integrator's Guide for the Cordex® CXC HP Controller | 3 - Using Modbus
Table 3-31 AMPS HP modular inverter system bypass switch with XMBS data points
Name Register Format
State 02:Input Status Boolean
Bypass Active 02:Input Status Boolean
Utility-Inverter Sync. Request Fault 02:Input Status Boolean
Bypass Hardware Fault 02:Input Status Boolean
Table 3-32 AMPS HP modular inverter system bypass switch data points
Name Register Format
State 02:Input Status Boolean
Bypass Active 02:Input Status Boolean
Table 3-33 AMPS HP modular inverter system breakers/fuse data points
Name Register Format
State 02:Input Status Boolean
Open Breaker/Fuse 02:Input Status Boolean
Table 3-34 AMPS HP modular inverter system T2S data points
Name Register Format
CAN Serial Number 04:Input Register 32-bit Integer
# Communicating Inverters 04:Input Register 32-bit Floating Point
# Comms Lost Inverters 04:Input Register 32-bit Floating Point
Table 3-35 AMPS HP modular inverter system TSI inverters data points
Name Register Format
AC Output Status 04:Input Register 32-bit Floating Point
On = 0
0350114-J0 Rev N Page 41
