Modbus Integrator's Guide for the Cordex® CXC HP Controller | 3 - Using Modbus
Table 3-35 AMPS HP modular inverter system TSI inverters data points (continued)
Name Register Format
• Manual Off = 1
• Irrecoverable Error = 2
• Recoverable Error = 3
AC Input Status 04:Input Register 32-bit Floating Point
See AC Output Status to decode
DC Input Status 04:Input Register 32-bit Floating Point
See AC Output Status to decode
Phase 04:Input Register 32-bit Floating Point
AC In Group 04:Input Register 32-bit Floating Point
DC In Group 04:Input Register 32-bit Floating Point
AC Output Power (VA) 04:Input Register 32-bit Floating Point
Loading (VA) 04:Input Register 32-bit Floating Point
DC In Current 04:Input Register 32-bit Floating Point
Nominal Output Power 04:Input Register 32-bit Floating Point
Nominal Input Voltage 04:Input Register 32-bit Floating Point
Bay ID 04:Input Register 32-bit Floating Point
Shelf ID 04:Input Register 32-bit Floating Point
Slot ID 04:Input Register 32-bit Floating Point
Active Alerts 04:Input Register 32-bit Floating Point
Software Version 04:Input Register 32-bit Floating Point
Input Current 04:Input Register 32-bit Floating Point
AC Input Power (VA) 04:Input Register 32-bit Floating Point
Input Frequency 04:Input Register 32-bit Floating Point
DC Input Voltage 04:Input Register 32-bit Floating Point
Output Current 04:Input Register 32-bit Floating Point
AC Output Power (W) 04:Input Register 32-bit Floating Point
Loading (W) 04:Input Register 32-bit Floating Point
Temperature 04:Input Register 32-bit Floating Point
Page 42 0350114-J0 Rev N
