Modbus Integrator's Guide for the Cordex® CXC HP Controller | 3 - Using Modbus
Table 3-19 FlexAir® ADIO data points (continued)
Name Register Format
T2 04:Input Register 32-bit Floating Point
T3 04:Input Register 32-bit Floating Point
T4 04:Input Register 32-bit Floating Point
T5 04:Input Register 32-bit Floating Point
Fan 1 Speed 04:Input Register 32-bit Floating Point
Fan 2 Speed 04:Input Register 32-bit Floating Point
Fan 3 Speed 04:Input Register 32-bit Floating Point
Fan 4 Speed 04:Input Register 32-bit Floating Point
Fan 5 Speed 04:Input Register 32-bit Floating Point
Fan 6 Speed 04:Input Register 32-bit Floating Point
Fan 7 Speed 04:Input Register 32-bit Floating Point
Fan 8 Speed 04:Input Register 32-bit Floating Point
Table 3-20 Smart Bypass ADIO data points
Name Register Format
CAN Serial Number 04:Input Register 32-bit Integer
Utility Phase L1 Voltage 04:Input Register 32-bit Floating Point
Utility Phase L2 Voltage 04:Input Register 32-bit Floating Point
Utility Phase L3 Voltage 04:Input Register 32-bit Floating Point
Inverter Phase L1 Voltage 04:Input Register 32-bit Floating Point
Inverter Phase L2 Voltage 04:Input Register 32-bit Floating Point
Inverter Phase L3 Voltage 04:Input Register 32-bit Floating Point
AC Load Phase L1 Voltage 04:Input Register 32-bit Floating Point
AC Load Phase L2 Voltage 04:Input Register 32-bit Floating Point
AC Load Phase L3 Voltage 04:Input Register 32-bit Floating Point
Utility Phase L1 Current 04:Input Register 32-bit Floating Point
Utility Phase L2 Current 04:Input Register 32-bit Floating Point
Utility Phase L3 Current 04:Input Register 32-bit Floating Point
0350114-J0 Rev N Page 25
