Modbus Integrator's Guide for the Cordex® CXC HP Controller | 3 - Using Modbus
Table 3-28 DC system current transducer (CT) data point
Name Register Format
CT/397: Current 04:Input Register 32-bit Floating Point
Table 3-29 DC system rectifiers data points
Name Register Format
CAN Serial Number 04:Input Register 32-bit Integer
AC Input Voltage 04:Input Register 32-bit Floating Point
Output Current 04:Input Register 32-bit Floating Point
Ambient Temperature 04:Input Register 32-bit Floating Point
Output Voltage 04:Input Register 32-bit Floating Point
Bay ID 04:Input Register 32-bit Floating Point
Shelf ID 04:Input Register 32-bit Floating Point
Slot ID 04:Input Register 32-bit Floating Point
Table 3-30 AMPS HP modular inverter system data points
Name Register Format
T2S Comms Lost 02:Input Status Boolean
Inverter Comms Lost 02:Input Status Boolean
Inverter Fan Failure 02:Input Status Boolean
Inverter Internal Error 02:Input Status Boolean
Inverter Restarts 02:Input Status Boolean
Inverter Overload 02:Input Status Boolean
Inverter Configuration Error 02:Input Status Boolean
Inverter Output Voltage Change in
Progress
02:Input Status Boolean
Inverter Not Ready 02:Input Status Boolean
Inverter Temperature Derating 02:Input Status Boolean
0350114-J0 Rev N Page 33
