Modbus Integrator's Guide for the Cordex® CXC HP Controller | 3 - Using Modbus
Table 3-20 Smart Bypass ADIO data points (continued)
Name Register Format
Inverter Phase L1 Current 04:Input Register 32-bit Floating Point
Inverter Phase L2 Current 04:Input Register 32-bit Floating Point
Inverter Phase L3 Current 04:Input Register 32-bit Floating Point
AC Load Phase L1 Current 04:Input Register 32-bit Floating Point
AC Load Phase L2 Current 04:Input Register 32-bit Floating Point
AC Load Phase L3 Current 04:Input Register 32-bit Floating Point
Table 3-21 Polarium Protocol Bridge data points
Name Register Format
Circuit Breaker Alert 02:Input Status Boolean
Anti-Thief Protection Alert 02:Input Status Boolean
Short Circuit Alert 02:Input Status Boolean
Temperature Over Limit 02:Input Status Boolean
Battery Under Voltage 02:Input Status Boolean
Temperature Too Low 02:Input Status Boolean
CAN Serial Number 04:Input Register 32-bit Integer
Number of Batteries 04:Input Register 32-bit Floating Point
# Batteries with Charge Blocked 04:Input Register 32-bit Floating Point
# Battery with Charge Completed 04:Input Register 32-bit Floating Point
Total Battery Current 04:Input Register 32-bit Floating Point
Average State of Charge 04:Input Register 32-bit Floating Point
Average State of Health 04:Input Register 32-bit Floating Point
Total Nominal Capacity 04:Input Register 32-bit Floating Point
Lowest State of Health 04:Input Register 32-bit Floating Point
Highest Cycle Count 04:Input Register 32-bit Floating Point
Highest Battery Voltage 04:Input Register 32-bit Floating Point
Lowest Battery Voltage 04:Input Register 32-bit Floating Point
Lowest Float-Charging Voltage 04:Input Register 32-bit Floating Point
Page 26 0350114-J0 Rev N
