Modbus Integrator's Guide for the Cordex® CXC HP Controller | 3 - Using Modbus
Table 3-23 DC system lead-acid battery data points
Name Register Format
Battery Charge Current High 02:Input Status Boolean
Battery Temperature High 02:Input Status Boolean
Battery Temperature Low 02:Input Status Boolean
Battery Breaker/Fuse Open 02:Input Status Boolean
Midpoint #1 Unbalanced (Deprecat-
ed)
02:Input Status Boolean
Midpoint #2 Unbalanced (Deprecat-
ed)
02:Input Status Boolean
Battery Temperature Anomaly 02:Input Status Boolean
Battery Mode 04:Input Register 32-bit Floating Point
This value corresponds to the
mode of the battery as follows:
• Unknown = 0
• NoBattery = 1
• Disconnected = 2
• Discharging = 3
• Charging = 5
• Battery Test = 6
• Float = 10
• Equalize = 11
• Boost = 12
Table 3-24 DC System Polarium battery data points
Name Register Format
Battery Temperature High 02:Input Status Boolean
Battery Temperature Low 02:Input Status Boolean
Battery Breaker/Fuse Open 02:Input Status Boolean
Battery On Discharge 02:Input Status Boolean
Voltage 04:Input Register 32-bit Floating Point
Current 04:Input Register 32-bit Floating Point
Page 30 0350114-J0 Rev N
