Modbus Integrator's Guide for the Cordex® CXC HP Controller | 3 - Using Modbus

Table 3-22 DC system data points (continued)

Name Register Format

Estimated AC Phase 3 Voltage 04:Input Register 32-bit Floating Point

Estimated Required Capacity 04:Input Register 32-bit Floating Point

Estimated Available Capacity 04:Input Register 32-bit Floating Point

Estimated Redundant Capacity 04:Input Register 32-bit Floating Point

Estimated Standby Capacity 04:Input Register 32-bit Floating Point

# Acquired Rectifiers 04:Input Register 32-bit Floating Point

# Sourcing Rectifiers 04:Input Register 32-bit Floating Point

# Failed Rectifiers 04:Input Register 32-bit Floating Point

# Minor Alarm Rectifiers 04:Input Register 32-bit Floating Point

# Non-Communicating Rectifiers 04:Input Register 32-bit Floating Point

# Communicating Rectifiers 04:Input Register 32-bit Floating Point

# AC Failed Rectifiers 04:Input Register 32-bit Floating Point

# Power Limiting Rectifiers 04:Input Register 32-bit Floating Point

# Current Limiting Rectifiers 04:Input Register 32-bit Floating Point

# Fan Fail Rectifiers 04:Input Register 32-bit Floating Point

# Rectifiers in Bootloader 04:Input Register 32-bit Floating Point

Battery Temperature 04:Input Register 32-bit Floating Point

Estimated State of Charge (Depre-

cated)

04:Input Register 32-bit Floating Point

Estimated Battery Runtime 04:Input Register 32-bit Floating Point

Estimated Battery Health (Depre-

cated)

04:Input Register 32-bit Floating Point

# Modules Supplying Power 04:Input Register 32-bit Floating Point

# Modules In Standby 04:Input Register 32-bit Floating Point

# Maximum Rectifier Ambient Tem-

perature

04:Input Register 32-bit Floating Point

# Load Current 04:Input Register 32-bit Floating Point
