EnerSys Alpha Cordex CXC HP Integrator Guide

Modbus Integrator's Guide for the Cordex® CXC HP Controller | 3 - Using Modbus
Table 3-22 DC system data points (continued)
Name Register Format
Temp Comp Measurement Fail
(Deprecated)
02:Input Status Boolean
Temp Comp Voltage Warning (Dep-
recated)
02:Input Status Boolean
Battery Runtime Low 02:Input Status Boolean
Battery Health Low (Deprecated) 02:Input Status Boolean
Rectifier Configuration Error 02:Input Status Boolean
Insufficient Capacity Remaining (A) 02:Input Status Boolean
Insufficient Capacity Remaining
(W)
02:Input Status Boolean
Missing Rectifier 02:Input Status Boolean
Rectifier AC Fail Count High 02:Input Status Boolean
Rectifier AC Fail Count Very High 02:Input Status Boolean
Total Load Current High 02:Input Status Boolean
Total Load Current Very High 02:Input Status Boolean
System Voltage 04:Input Register 32-bit Floating Point
Estimated AC Input Voltage 04:Input Register 32-bit Floating Point
Total Load Current 04:Input Register 32-bit Floating Point
Expected Load Current in AC Fail 04:Input Register 32-bit Floating Point
Battery Voltage 04:Input Register 32-bit Floating Point
Battery Current 04:Input Register 32-bit Floating Point
Total Output Current 04:Input Register 32-bit Floating Point
Total Output Power 04:Input Register 32-bit Floating Point
Total Capacity Installed (A) 04:Input Register 32-bit Floating Point
Total Capacity Installed (W) 04:Input Register 32-bit Floating Point
Estimated Capacity Remaining (A) 04:Input Register 32-bit Floating Point
Estimated Capacity Remaining (W) 04:Input Register 32-bit Floating Point
Average Rectifier Output Voltage 04:Input Register 32-bit Floating Point
Estimated AC Phase 1 Voltage 04:Input Register 32-bit Floating Point
Estimated AC Phase 2 Voltage 04:Input Register 32-bit Floating Point
Page 28 0350114-J0 Rev N
