Modbus Integrator's Guide for the Cordex® CXC HP Controller | 3 - Using Modbus
3.5.2. Limited data set data points
This section lists the available data points when using the limited data set.
3.5.2.1. Data points
This section lists the Modbus data values available for the limited data set.
Table 3-36 Limited data set data points
Decimal ad-
dress
Register Name Format
30001 04:Input Register System Voltage 32-bit Floating Point
30003 04:Input Register Total Load Current 32-bit Floating Point
30005 04:Input Register Total Capacity Installed in Amps 32-bit Floating Point
30007 04:Input Register Battery Mode 32-bit Floating Point
This value corresponds to the
mode of the battery as follows:
• Unknown = 0
• NoBattery = 1
• Disconnected = 2
• Discharging = 3
• Conditioning (FL or EQ)
= 4
• Charging = 5
• Battery Test = 6
30009 04:Input Register Estimated Rectifier AC Input Volt-
age
32-bit Floating Point
30011 04:Input Register Estimated Battery Runtime 32-bit Floating Point
30013 04:Input Register Last Discharge Duration 32-bit Floating Point
30015 04:Input Register Output Voltage Low Alarm Limit 32-bit Floating Point
30017 04:Input Register Output Voltage High Alarm Limit 32-bit Floating Point
30019 04:Input Register Battery Runtime Low Alarm Limit 32-bit Floating Point
30021 04:Input Register AC Mains Voltage Low Alarm
Limit
32-bit Floating Point
30023 04:Input Register AC Mains Voltage Hight Alarm
Limit
32-bit Floating Point
30025 04:Input Register Battery: Capacity Rating 32-bit Floating Point
0350114-J0 Rev N Page 43
