TS-12 Musician’s Manual Section 7 — Effect Parameters
3
1 LEVEL to create a natural sounding echo.
REF-2 SEND Range: 00 to 99
Controls the level of the second pre-echo, with the echo routed directly to the output.
DETUNE - RATE Range: 00 to 99
Controls the LFO rate of detuning introduced into the reverberation decay. Detuning creates a
slight oscillating pitch shift into the decay, giving it a more natural sound by breaking up
resonant nodes.
DEPTH Range: 00 to 99
Controls the depth of the detuning, that is, how much the pitch will change. Low values yield a
metallic sound. Some sounds may require very low values, while others sound more natural
with higher values.
L/R BALANCE Range: -99 to +99
Controls the left/right stereo balance of the gated reverb signal. A setting of -99 would offer hard
left, whereas a setting of +99 would offer hard right. A setting of +00 would place the reverb in
the center of the stereo spectrum.
PRIMARY SEND Range: -99 to +99
Controls the level of the diffused input signal into the reverb definition.
33 TIGHT AMBIENCE
34 WIDE AMBIENCE
TIGHT AMBIENCE provides room ambience. WIDE AMBIENCE provides a larger ambient
room reverb. These two algorithms offer studio quality ambient reverbs that can be controlled
with a high degree of precision. The FX-1 and FX-2 parameters can be routed into the effect with
different Dry/Wet mixes.
These algorithms share essentially the same signal routing topology as HALL REVERB 2.
However, the internal values of the components (not user-programmable) differentiate these
three reverbs.
DECAY TIME Tight Ambience Range: 0.20 to 100.0 sec
Wide Ambience Range: 0.20 to 150.0 sec
Controls the amount of time it takes for the reverberation to decay to a very low level after the
input signal stops. In these reverbs we don’t recommend higher settings, which tend to create an
infinite and unnatural sustain. Since most ambient reverbs don’t naturally have a large decay, set
this low for the best sound.
PRE-DLY TIME Range: 0000 to 0500 msec
Controls the amount of time it takes for the original signal to be presented to the reverb. Higher
values denote a longer delay.
HF - DAMPING Range: 00 to 99
Controls the rate of attenuation of high frequencies in the decay of the reverberation. As natural
reverb decays, some high frequencies tend to get absorbed by the environment. Increasing the
value of this parameter will gradually filter out (dampen) more and more high-frequency energy.
