ENSONIQ TS-12 User Manual

Appendix TS-12 Musician’s Manual
II
MODEL: TS-12 MIDI Implementation Chart
Version: 2.0
Function… Transmitted Recognized Remarks
Basic
Channel
Default
Channels
1
1-16
1
1-16
Mode
Default
Messages
Altered
1
X
X
1, 3, 4, MULTI
X
X
current mode is memorized
Global Controllers in MONO
Mode
Note
Number
True Voice 21-108 21-108
Velocity
Note ON
Note OFF
O
O
O
X
1
1
The TS-12 voice
architecture does not
support Release Velocity
After
Touch
Key
Channel
X
O
O
O
Pitch Bender O O
Control
Change
1–127 External Controller
0 Bank Select MSB
1 Mod Wheel
4 Foot Pedal
6 Data Entry MSB
2
7 Volume
10 Pan
12 Effect Mod Foot Switch
32 Bank Select LSB
38 Data Entry LSB
2
64 Sustain
66 Sostenuto
70 Sound Variation
3
71 Harmonic Content
4
72 Release Time
73 Attack Time
74 Brightness
75 Rate (LFO &/or Duration)
100 Reg. Param. Select LSB
5
101 Reg. Param. Select MSB
6
1–127 External Controller
0 Bank Select MSB
1 Mod Wheel
4 Foot Pedal
6 Data Entry MSB
2
7 Volume
10 Pan
12 Effect Mod Foot Switch
32 Bank Select LSB
38 Data Entry LSB
2
64 Sustain
66 Sostenuto
70 Sound Variation
3
71 Harmonic Content
4
72 Release Time
73 Attack Time
74 Brightness
75 Rate (LFO &/or Duration)
100 Reg. Param. Select LSB
5
101 Reg. Param. Select MSB
6
assignable (XCTRL)
2
for Reg. Params only after
100 & 101 are transmitted
or received.
3
Patch Selects; values of 0,
32, 64, 127
4
Timbre
5
values of 0 & 1 only
6
always 0
Program
Change
True Number
0-127
0-127
0-119
0-119
in OMNI, POLY, & MONO A
in MULTI & MONO B
System Exclusive O O see TS-12 Sys-Ex Spec.
System
Common
: Song Pos
: Song Sel
: Tune
O
O
X
O
O
X
System
Real Time
: Clocks
: Commands
O
O
7
O
O
7 7
Start, Stop, Continue
Aux.
Messages
: Local On/Off
: All Notes Off
: Active Sense
: Reset
X
O
X
O
X
O
X
O
Notes
Mode 1= OMNI ON, POLY
Mode 3= OMNI OFF, POLY
Mode 2= OMNI ON, MONO
Mode 4= OMNI OFF, MONO
O = YES
X = NO
