TS-12 Musician’s Manual Section 8 — Understanding Programs
13
• KEYBD — Keyboard Tracking
This uses the position of a note on the keyboard as a modulator. The scaling effect of this
Modulator is based on a 76-note keyboard:
+100
+50
0
-50
-100
TS-10 (a 61-note keyboard)
TS-12 (a 76-note keyboard)
MIDI Key numbers 0-127
As the above illustration shows, the effect of KEYBD as a modulator goes negative as well as
positive. The effect of KEYBD is to reduce the Level on notes below the break point (F4+), and
increase levels above that point. Negative Modulation depths will do the opposite.
• VELOC — Velocity
Velocity means how hard you strike a key. Selecting VELOC as a Modulator allows you to
modulate any manual level with velocity. Velocity as a modulation source only goes positive
(though assigning a negative modulation amount will make the net result be to reduce the
level with increased velocity).
• *OFF*
Modulation is disabled.
