1. Drill screw holes for the wall brackets.
2. Select applicable screws for the the wall.
3. Attach the extension box to the wall with 4 fastening screws.
4. See wiring instructions on page 16.
6.3. Wall mounting
Installation accessories
Screws max. Ø 6mm (not included) 4 pcs
Installation steps
1075
500
1575
285
The socket outlet will be at
a height of 1200 mm
