RAK139_ENG / 2023-09-14
25 / 36
Design and mechanics
Materials Frame and extension box: Powder coated mild steel
Cover: Plastic (PETG and ABS)
Sticker on the cover: Black
Color Frame and extension box: RAL7021 “Anthracite”
Cover: White and black tape
Weight Total approx. 23 kg
• charger: approx. 10 kg
• extension box: approx. 13 kg
Ingress protection rating IP54
Shock protection rate IK10
Operating temperature -25 °C … +50 °C
Standard IEC 61851-1, general requirements for electric vehicle conductive
charging system
Approvals / markings CE
Electrical connections
Nominal supply voltage * 3-ph, 400 VAC
Charging current (nominal) 3 x 32A
Charging power (nominal) 2 x 22kW
Supply connections and
terminals
L1, L2, L3, N, PE
Cu 2.5–50 mm² (according to supply current and local regulations)
Tightening torque: 4 Nm (2.5 - 4 mm²), 10 Nm (6 - 50 mm²)
Grid connections TN (3-ph) / IT (2-ph, 230Vp-p)
* Supply voltage range 208 ... 264 V.
Please note that typically electric vehicles do not tolerate more than 7 volts of uctuation in the main
voltage.
9. Technical data
User interface
Socket outlet Mode 3 / Type 2
Charging status indication 3-color LED
• Green / Ready
• Blue / Charging
• Red / Error
Use access RFID (ISO/IEC 14443A, ISO/IEC 15693)
Free access
Mobile apps via 3rd party operators
ISO15118 (Plug & Charge support)
Energy measurement MID class kWh meter
