14. Testing instructions for the electric protective device (RCBO)
• Press the TEST button.
• The rocker turns to 0 position.
• Turn the rocker back to I position.
• If a fault occurs, contact an electrician.
15. Troubleshooting
Charging station is o, no lights on
Issue Corrective action
Mains voltage does not exist in the supply con-
nectors (L1, L2, L3).
Make sure that the supply conductors are properly
connected. Make sure that there is power available.
The circuit breaker F0 is o. Turn the F0 on.
The PWR LED indicator on the controller is not
on.
Make sure that power supply to the controller is avail-
able.
Charging cable is locked in Mode 3 socket outlet
Issue Corrective action
Unexpected fault has occurred while the power
is on.
Turn o the power from the F0 and pull the charging
cable out from the socket.
The power is o. Open the front cover. Switch the Mode 3 lock into
open position.
Conguration via web browser
Issue Corrective action
The PC does not recognize the USB plug and a
connection to the controller cannot be estab-
lished via web browser.
Make sure from Windows operating system settings
via “Device Manager” that RNDIS network adapter is
available. If not, contact your local IT support.
