12. Installation / Commissioning checklist
Introduction
Examine the mechanical and electrical installation in accordance with this checklist to make sure that the
charging station is properly installed.
Checking the Installation
Examine the visual, mechanical and electrical installation when the charging station is un-
powered.
CATEGORY X ITEM
Overall look You have received the ordered material.
You have removed the protective plastic wrapping.
You do not see any scratches or damages.
Mechanical
installation
The charging station is mounted properly on the installation site.
Electrical
installation
The charging station’s power supply capacity meets electrical planning (cable size,
protective devices…). Review the local electrical design plan.
The PE-cable screw is tight.
The power supply conductors (L1, L2, L3, N and PE) are properly connected.
The insulation of the power supply cable and the conductors (L1, L2, L3, N and PE)
is intact.
The voltage between PE and N is less than 10 V.
The PE conductor resistance is less than 3 Ω.
Operational
check
All the LED states / colors (green, blue, red) and the RFID reader are functioning.
• Use a car simulator.
• Create fail and charge.
• Red at bootup, green at idle and blue while charging.
Test the functionality of the electric protective device (RCBO).
Ready for use The correct SW is in use.
Correct operating mode
• Standalone
• Online
Test the data communication, if it is in use.
Examine the available signal strength to make sure that the communication (4G,
WiFi), reception and connectivity are working.
