Enterasys 2H25x - Port Redirect Configuration Screen; Port Redirect Configuration Screen Field Descriptions

Port Redirect Configuration Screen
Port Configuration Menu Screens 5-15
Figure 5-5 Port Redirect Configuration Screen
Field Descriptions
Refer to Table 5-5 for a functional description of each screen field.
Table 5-5 Port Redirect Configuration Screen Field Descriptions
Use this field… To…
Source Port
(Read-Only)
See which ports are currently set as source ports.
Destination Port
(Read-Only)
See which ports are currently set as destination ports. Only one
destination port may be assigned to a source port.
Frame Format
(Read-Only)
See the current frame format setting: NORMAL, TAGGED or
UNTAGGED. The default is NORMAL.
NORMAL – Frames are redirected in the format that they were
received or transmitted on the source port.
TAGGED – Frames are transmitted on the destination port with a
VLAN tag inserted according to the frame classification.
UNTAGGED – Frames are transmitted on the destination port without
a VLAN tag regardless of the format of the received frame.
