45
IP1967EN - 2016-08-01
Command Function Description
SOFA1-SOFA2
GOPAVRS
0411
SAFETY TEST Insert the electronic card SOFA1-SOFA2 or GOPAVRS in the
housing AUX on the control panel.
Selecting
, the terminal 41 activates a safety
edge test before each operation. If the test fails, an alarm mes-
sage is visualised on the display.
1
6 N.C. OPENING SAFETY
DEVICE
Selecting
, connect the output contact of device
SOFA1-SOFA2 to terminals 1-6 on the control panel (in series with
the photocell output contact, if installed).
1 8 N.C. REVERSAL
SAFETY
CONTACT
Selecting
, connect the output contact of device
SOFA1-SOFA2 to terminals 1-8 on the control panel (in series
with the photocell output contact, if installed).
5.1 SOFA1-SOFA2 or GOPAVRS self-controlled safety edge
