1.2. Additional documentation
You can find additional documentation in the documentation directory of the installation
media for your product. For information about enabling additional features (such as
client licenses), see the User Guide. We strongly recommend that you read the release
notes before you use the module. These notes contain the latest information about your
product and are available online through Entrust nShield support
https://nshieldsupport.entrust.com.
Read this guide in conjunction with the nShield product’s Warnings and Cautions
documentation (available in multiple languages).
1.2.1. Terminology
The nShield Connect is referred to as the nShield Connect, the hardware security module,
or the HSM.
1.3. Handling an nShield Connect
An nShield Connect contains solid-state devices that can withstand normal handling.
However, do not drop the module or expose it to excessive vibration.
If you are installing the module in a 19” rack, make sure that you follow the nShield
Connect Slide Rails Instructions provided with the rails. In particular, be careful of sharp
edges.
Only experienced personnel should handle or install an nShield Connect. Always consult
your company health and safety policy before attempting to lift and carry the module.
Two competent persons are required if it is necessary to lift the module to a level above
head height (for example, during installation in a rack or when placing the module on a
high shelf).
1.3.1. Weight and Dimensions
Weight:ÊÊ11.5kg
Dimensions:Ê43.4mm x 430mm x 690mm
The module is compatible with 1U 19” rack systems.
Measurements given are height x width x length/depth. If the inner slide rails are
attached, the width of the unpackaged module is 448mm.
nShield® Connect Installation Guide 6 of 73
