Standalone layers explained
When creating a standalone the light output should be visualized as two layers:
 Background (controls shown in red)
 Foreground (controls shown in blue)
The OCTO has colour wheel support for both RGB WWA (warm white, cool white and Amber)
pixel tape
Background
By only enabling the background layer the pixel tape/dots will respond like a standard RGB
tape. The background can be:
 Set to a constant color.
 Dimmed
 Made to strobe
The controllers affect the entire length up to the maximum possible pixels (e.g., 680 3-
channel pixels).
Foreground
This layer creates effects that overlay on the background colour. The foreground can be:
 Set to a constant color.
 Dimmed
 Made to strobe
 Set to create patterns
Master intensity
Master intensity controls the overall brightness of the output (both for foreground and
background). Where:
 0 – no LEDs ON
 255 – LEDs on are at full brightness
Background/ foreground strobe frequency
Controls the time between LED(s) on and off time:
 0 – LEDs switch on and off at slowest speed
 255 – LEDs switch on and off at fastest speed
