Enttec OCTO User Manual


USER GUIDE - v1.0
ID: 5928937
15 |
OCTO – 71521
Visit the ENTTEC website for
the latest version
DMX protocols
KiNET
Supported commands:
 Discover device
 Discover ports on device
 Change device name
 Change device IP
 Portout commands
 DMX out commands
 KGet Command
 KGet Subnet Mask
 KGet Gateway
 KGet port universe (port 1 and 2)
 KSet commands
 KSet Subnet Mask
 KSet Gateway
 KSet port universe (port 1 and 2)
 KSet device to boot
Art-Net
Supports Art-NET 1/2/3. Each output port can be assigned a start universe in the range 0 to 32764.
sACN
Outputs can be assigned a start universe in the range 1-63996 (when universe/output = 4).
Note
The OCTO supports a maximum of 1 multicast universe with sACN sync. (i.e., all universes set to the
same value)
ESP
Outputs can be assigned a start universe in the range 0-252 (when universe/output = 4). More
details of the ESP protocol can be found at www.enttec.com
Universes/Outputs
The OCTO converts up to four universes of DMX over Ethernet to pixel data per output.
Both outputs can be specified to use the same universes, e.g., both outputs use universe 1,2,3 and 4.
Each output can also be specified to use its own individual group of universes, e.g., output 1 uses
universes 100,101,102 and 103 however output 2 uses 1,2,3 and 4.
Only the first universe can be specified; the remaining universes, second, third and fourth are
automatically assigned subsequent universes to the first one.

Enttec OCTO Specifications

General

Brand	Enttec
Model	OCTO
Category	Controller
Language	English
