Shenzhen Envicool Technology Co., Ltd.
Less than 30 condensers are installed separately
The condenser spacing in the picture requires the height of the surrounding wall
without railings h≤0.5m. When the height of the external wall without railings h> 0.5m,
the base of the outdoor unit needs to be increased accordingly (h-0.5) m;
No obstruction within 5000mm of condenser air outlet;
The condenser requires a maintenance space of at least 1300mm front and back or
left and right;
If the condenser needs to be transported twice during installation, the distance
between the condensers must be sufficient according to the actual handling situation;
The space requirements described below are based on the minimum separation
distance within 10m around the place where the condenser is installed without
high-rise buildings blocking air circulation.
Fig. 2-15 Schematic diagram of side by side installation space
