11
Maintenance And Service
gLass DooR RemoVaL:
cLeaning the PainteD suRfaces:
Painted surfaces should be periodically wiped with a damp cloth when the unit is cool.
Warning: Do not touch or attempt to remove the glass if the replace is not completely cool.
Never operate the replace with the glass removed.
CAUTION GLASS MAY SEPARATE FROM DOOR.
Figure 8: Door Release.
Figure 9: Door Removal.
Remove the glass door by placing the hooked end of the door release tool in the hole on the
door latch mechanism (see Figure 8) and pulling the latch out then up. When the two (2)
latches have been released, tilt the bottom of the door forward and then lift up to unhook
the top door tabs (see Figure 9).
Re-assemble in the reverse order.
