Envirosight Verisight Pro+ - CCU Overview: Front View

Envirosight Verisight Pro
+
1 Loudspeaker
2 High Resolution TFT Screen
800 x 600 pixels
3 Video Output
4 Joystick
5 Cursor Control Keys
6 Special Function Keys
7 Camera Keys
8 Power ON/OFF
9 Media Keys
10 QWERTY style Keyboard
11 Survey Keys
12 Special Function Keys
13 Multi-function “Hot” Keys
14 Protective Flap for USB or
SD Card
CCU Overview
Front view
1
12 10 7
14
3
5
11
2
6
4
9 8
13
27
Version A
