Envirosight Verisig
ht Pro+
Pan-and-Tilt Camera Operation and Control
This section describes the operation and control of the Pan & Rotate camera on
the Verisig
ht Pro+
system.
Basic camera operation
When the Verisig
ht Pro+
CCU is first switched on the joystick is active.
There is a set procedure to follow to operate the camera:
• Home
• Check Pressure
When using the joystick extra symbols are displayed on the right hand side of
the display. These are not recorded on the video but provide a visual cue to the
operator of the camera pressure and rotation.
A further two symbols are drawn on the top left of the display showing pan and
rotation angles. These are recorded on the video.
Home
Press the Home key.
The camera head returns to the home position. After the homing is complete
the camera will now auto-level when in use until the joystick is moved. If the
joystick is moved, press the Home key to home the camera and to enable
auto-level again.
NOTE! The camera will only home when it is positioned within
+/-45 degrees of horizontal. Otherwise it is unaware of which way
is up! If the camera fails to home check the camera body position.
Likewise the auto-level feature will only work up to +/-45 degrees from horizontal.
92
Version A
