Epever Tracer AN series User Manual

33
Recommended cable
6AWG/ 16mm
2
Net Weight
3.5kg
① When connecting the controller to external devices, only one of the communication ports is
used; when connecting multiple controllers in parallel, RS485 ports are for cascaded use.
Model
Tracer6210AN
Electrical Parameters
System rated voltage
12/24/36/48VDC or Auto
Controller working
voltage range
8V~32V
Lead-acid battery type
Sealed(default), GEL, FLD, and user-defined.
Lithium battery type
LiFePO4/ Li(NiCoMn)O2/ User
Battery fuse
80A/ 58V
Rated charging current
60A
Rated charging power
750W/12V, 1500W/24V
Max. PV open-circuit
voltage
100V(at the lowest temperature)
92V(at 25℃)
MPPT voltage range
(Battery voltage +2V)
~72V(at 25℃)
MPPT tracking efficiency
≥99.5%
Max. conversion
efficiency
98.0%
Full load efficiency
97.0%
Temperature
compensate coefficient
-3mV/℃/2V(Default)
Self-consumption
98mA/12V; 60mA/24V; 50mA/36V; 46mA/48V
Grounding type
Common negative grounding
Dry contact
Rated value: 5A/30VDC; Max. value: 0.5A/60VDC
Communication method
RS485(5VDC/200mA, Two RJ45 ports in parallel)
①
LCD backlight time
Default: 60S, Range:0~999S (0S: the backlight is ON all the
time)
Mechanical parameters
Dimension
340×232×105.2mm
Mounting dimension
260×220mm
Mounting hole size
Φ7
