Epever Tracer AN series User Manual

35
Mounting dimension
260×224mm
Mounting hole size
Φ7
Wire size
2AWG/ 35mm
2
Recommended cable
6AWG/ 16mm
2
Net Weight
4.5kg
① When connecting the controller to external devices, only one of the communication ports is
used; when connecting multiple controllers in parallel, RS485 ports are for cascaded use.
Model
Tracer8415AN
Tracer8420N
Electrical Parameters
System rated voltage
12/24/36/48VDC or Auto
Controller working
voltage range
8V~68V
Lead-acid battery type
Sealed(Default)/Gel/Flooded/User
Lithium battery type
LiFePO4/ Li(NiCoMn)O2/ User
Battery fuse
125A/ 58V
Rated charging current
80A
Rated charging power
1000W/12V, 2000W/24V, 3000W/36V, 4000W/48V
Max. PV open-circuit
voltage
150V(at the lowest
temperature)
138V(at 25℃)
200V(at the lowest
temperature)
180V(at 25℃)
MPPT voltage range
(Battery voltage +2V)
~ 108V(at 25℃)
(Battery voltage +2V)
~ 144V(at 25℃)
MPPT tracking efficiency
≥99.5%
Max. conversion
efficiency
98.5%
Full load efficiency
98.0%
97.5%
Temperature
compensate coefficient
-3mV/℃/2V(Default)
Self-consumption
98mA/12V; 60mA/24V; 50mA/36V; 46mA/48V
Grounding type
Common negative grounding
Dry contact
Rated value: 5A/30VDC; Max. value: 0.5A/60VDC
Communication method
RS485(5VDC/200mA, Two RJ45 ports in parallel)
①
LCD backlight time
Default: 60S, Range:0~999S (0S: the backlight is ON all the
time)
