Installing Options 223
EPSON AcuLaser C3800 User's Guide
6. Hold the memory module and insert it into the optional memory slot in the orientation
shown below until it stops. Then press both sides of the memory module down. Confirm
that the notch on the memory module matches that of the memory slot.
*notch
c
Caution:
❏ Do not apply too much force.
❏ Be sure to insert the memory facing the correct way.
❏ Do not remove any modules from the circuit board. Otherwise, the printer will not
work.
7. Reattach the controller option expanded aperture plate.
*
