4. Set the paper release lever to the front push tractor position. Also set the paper-thickness lever
(located under the printer cover) to the proper position for your paper’s thickness. See “Adjusting
the Paper Thickness Lever” on page 19 for instructions.
5. Release the left and right sprockets by pushing the blue sprocket lock levers backward.
6. Slide the left sprocket approximately 12 mm (0.5 inch) from the far left position and pull the blue
lever forward to lock it in place. Then slide the right sprocket to match the width of your paper, but
do not lock it.
* approx. 12 mm (0.5 inch)
LQ-590II/LQ-590IIN/LQ-2090II/LQ-2090IIN User’s Guide
Paper Handling 28
