61
Appendix
Pixelworks DNX
TM
IC is installed in this unit.
Composite Video/S-Video
Specifications / Compliant
Resolutions
Product name EMP-TWD1
Dimensions 340(W) x 180(H) x 310(D) mm (excluding feet)
Panel size 0.55-inch wide
Display method Polysilicon TFT active matrix
Resolution 409,920 pixels (854 (W) x 480 (H)dots) x 3
Focus adjustment Manual
Zoom adjustment Manual (approx. 1:1.5)
Lens shift Manual (vertical maximum approx. 50%, horizontal maximum approx. 25%)
Lamp (light source) UHE lamp, 135 W, Model No.: ELPLP33
Power supply
100-240VAC 50/60 Hz 2.6 - 1.2 A
Power Consumption
Operating: 230 W (100 - 120 V area), 220 W (220 - 240 V area)
Standby: 6 W (100 - 120 V area), 9 W (220 - 240 V area)
Operating temperature +5° - +35°C (No condensation)
Storage temperature -10° - +60°C (No condensation)
Weight Approximately 7.0kg
Connectors
Input
Audio port 1 RCA pin jack
S-Video port 1 Mini DIN 4-pin
Video port 1 RCA pin jack
Output
Subwoofer port 1 RCA pin jack
Optical Audio-Out port 1 Square optical jack
Headphone jack 1 3.5mm mini-jack
Speaker
Output sound wave pressure level 79 dB/Wm
Maximum input (JIS) 10W Rated impedance 4Ω
Audio output
Analog audio
output
1 speaker system: Practical, maximum output 10W + 10W
(10% THD JEITA/4Ω)
1 headphone system: 12 mW/32Ω
Acceptable impedance 16Ω - 1kΩ
1 subwoofer system (L+R): 0.25 Vrms/27 kΩ
Dynamic range 70 dB (JEITA) or more
Total harmonic distortion rate 0.5% (JEITA) or less
Digital audio
output
Light: -21dBm to -15 dBm
Readable disc types
DVD video, Video CD, SVCD, Audio CD, CD-R/RW (Audio CD, Video CD, SVCD, MP3/
WMA, JPEG format), DVD-R/RW (DVD video format)
Signal Resolution
Aspect Mode
Normal Wide
TV (NTSC) 640 × 480 640 × 480 (4:3) 854 × 480 (16:9)
TV(PAL, SECAM) 768 × 576 640 × 480 (4:3) 854 × 480 (16:9)
