Epson DS-770 II User Manual

Maintenance
Cleaning the Flatbed Scanner Dock
To keep your Flatbed Scanner Dock in optimum condition, follow the steps below to clean it periodically.
c
Important:
❏ Never use alcohol, thinner, or corrosive solvent to clean the Flatbed Scanner Dock. ese chemicals can damage
the Flatbed Scanner Dock components and the case.
❏ Be careful not to spill liquid into the scanner mechanism or electronic components. is could permanently
damage the mechanism and circuitry.
❏ Do not spray lubricants onto the Flatbed Scanner Dock.
❏ Never open the Flatbed Scanner Dock case.
1.
Press the
button to turn
o
the sheet feed scanner.
Note:
ere is no power button on the atbed scanner.
2.
Unplug the AC adapter, and then disconnect the USB cable that is connected to the computer from the Flatbed
Scanner Dock.
3.
Wipe o any dirt on the outer case with a so cloth.
If the case is very dirty, dampen a so cloth with water and wring it out thoroughly, and then wipe o any
remaining stains. Next, use a so dry cloth to wipe the case.
Using the Flatbed Scanner Dock > About the Flatbed Scanner Dock > Maintenance
143

Epson DS-770 II Specifications

General

Optical Resolution	600 dpi
ADF Capacity	100 sheets
Scan Speed	45 ppm / 90 ipm
Connectivity	USB 3.0
Duplex Scanning	Yes
Ultrasonic Double Feed Detection	Yes
Scanning Method	Contact Image Sensor (CIS)
Scan Speed (Color, A4, 300 dpi)	45 ppm
Scan Speed (Black & White, A4, 300 dpi)	45 ppm
Document Feeder Capacity	100 sheets
Interface	USB 3.0
Supported Operating Systems	Windows, Mac OS
Scanner Type	Sheetfed
Max Document Size	215.9 mm x 6096 mm
Grayscale Depth	10-bit
Maximum Resolution	1200 dpi
Maximum Document Size	215.9 mm x 6096 mm
Minimum Document Size	50.8 mm x 50.8 mm
Color Depth	Input: 30 Bits Colour / 10 Bits Monochrome , Output: 24 Bits Colour / 8 Bits Monochrome
