❏ Destination: Select the destination of the scanned images. You can send them by email or forward them to
an FTP server or Web server.
5.
Click OK to return to the Job List window.
e created job is registered in the Job List.
6.
Click OK to return to the main window.
Related Information
& “Scanning Using a Scanner Button” on page 63
Assigning a Job to the Scanner Button (Windows)
You can assign a job to the scanner's button, and run the job by pressing the button.
1.
Start Document Capture Pro.
2.
Click Job Settings > Button Assignment on the Job Scan screen.
3.
Click the job name to select the job you want to assign from the pull-down menu.
4.
Click OK to close the Button Assignment screen.
5.
Click Back.
Assigning a Job to the Scanner Button (Mac OS)
You can assign a job to the scanner's button, and run the job by pressing the button.
1.
Start Document Capture.
2.
Click the
(Manage Job) icon on the main window.
e Job Management window is displayed.
3.
Click the
icon at the bottom of the screen.
4.
Click the job name to select the job you want to assign from the pull-down menu.
5.
Click OK on the Job Management window.
e job is assigned to the scanner button.
Advanced Scanning > Setting a Job > Assigning a Job to the Scanner Button (Mac OS)
90

Epson DS-770 II Specifications

General

Optical Resolution	600 dpi
ADF Capacity	100 sheets
Scan Speed	45 ppm / 90 ipm
Connectivity	USB 3.0
Duplex Scanning	Yes
Ultrasonic Double Feed Detection	Yes
Scanning Method	Contact Image Sensor (CIS)
Scan Speed (Color, A4, 300 dpi)	45 ppm
Scan Speed (Black & White, A4, 300 dpi)	45 ppm
Document Feeder Capacity	100 sheets
Interface	USB 3.0
Supported Operating Systems	Windows, Mac OS
Scanner Type	Sheetfed
Max Document Size	215.9 mm x 6096 mm
Grayscale Depth	10-bit
Maximum Resolution	1200 dpi
Maximum Document Size	215.9 mm x 6096 mm
Minimum Document Size	50.8 mm x 50.8 mm
Color Depth	Input: 30 Bits Colour / 10 Bits Monochrome , Output: 24 Bits Colour / 8 Bits Monochrome
