Name Function
R
Audio-L/R port
Inputs audio from equipment connected to the S-Video
port or the Video port.
S
S-Video port
For S-video signals from video sources.
Base
Name Function
A
Ceiling mount fixing
points (three points)
Attach the optional Ceiling Mount here when suspending
the projector from a ceiling.
s "Installing the Projector" p.17
s "Optional Accessories" p.118
B
Wall mount plate
fixing points (five
points)
Attach the optional wall mount plate here when
suspending the projector from a wall.
s "Optional Accessories" p.118
Part Names and Functions
10
