Epson EB-W06 User Manual

Projector Lamp Maintenance
164
Warning
When replacing the lamp, there is a possibility that the lamp may be
broken. If replacing the lamp of a projector which has been installed on the
ceiling, you should always assume that the lamp is cracked, and you should
stand to the side of the lamp cover, not underneath it. Remove the lamp
cover gently. Be careful when removing the lamp cover as shards of glass
may fall out and could cause an injury. If any shards of glass get into your
eyes or mouth, contact a doctor immediately.
d
Slide the lamp cover out and lift it off.
e
Loosen the screws securing the lamp to the projector. The screws do
not come all the way out.
f
Grip the raised section of the lamp and remove it.

Epson EB-W06 Specifications

General

Contrast Ratio	16, 000:1
Weight	2.5 kg
Projection System	3LCD
Aspect Ratio	16:10
Projection Ratio	1.30 - 1.56:1
Screen Size	33 inches - 320 inches
Projection Lens F Number	1.49 - 1.72
Projection Lens Focal Length	16.9 - 20.28 mm
Projection Lens Focus	Manual
Security	Kensington lock, Password protection
3D	No
Resolution	WXGA (1280 x 800)
Brightness	3700 lumens
Lamp Life	12000 hours (Eco)
Keystone Correction	Vertical: ±30 degrees, Horizontal: ±30 degrees
Connectivity	HDMI, VGA, USB
LCD Panel	0.59-inch with MLA (D10)
Lamp	UHE, 210 W
Zoom	Factor: 1.2
Noise Level	37 dB (Normal)
Dimensions	302 x 237 x 82 mm (Width x Depth x Height)
Power Consumption	0.3 W (Standby)
