The Face-up Output Tray
Removing the face-up output tray
When you need to remove the face-up tray from the printer for
transportation or other purposes, follow the steps below.
1. Remove the face-up tray from the printer.
2.
Using a screwdriver, release the four screws from the drive
unit and remove the drive unit.
3. Replace the rear cover with the four screws,
CAUTION: Do not turn on the printer without the rear
cover or the face-up tray drive unit. You may cause
mechanical failure.
Appendix
A
A-29
