Assembling the Printer
WARNING: Never touch the fuser. When the printer is
in operation, the fuser becomes very hot.
3.
Hold the cleaning pad by the yellow handle and place the
cleaning pad into the indentation on top of the fuser. To make
sure you install the pad in the correct position, match the
triangle on the cleaning pad with the triangle on the fuser, as
shown below.
Installing the imaging cartridge
The imaging cartridge forms the image and transfers it onto the
paper. See Chapter 6 for information on imaging cartridge life.
CAUTION: The drum is light-sensitive. Do not expose it
to light any longer than necessary and do not expose it
to light brighter than normal room light.
Setting Up
the
Printer
1-13
