Epson GT-30000 Quick Start Manual

GT-30000
A5-Format Quick Start Manual_E.fm
1/11/01 Right
R
3
EN
■ Table of Contents
Where to Find Information . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 4
ENERGY STAR Compliance . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 5
Warnings, Cautions, and Notes . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 5
System Requirements . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 5
For Windows and SCSI users. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 5
For Windows and IEEE 1394 users . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 6
For scanning over a network . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 6
Scope of Delivery. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 7
Choosing a Place for the Scanner . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 8
Releasing the Transportation Lock. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 8
Plugging In the Scanner . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 9
Initializing the Scanner. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 10
Connecting the Scanner to Your PC Using the SCSI Interface . . . . . . . . . . 10
Understanding SCSI connections. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 11
Setting the SCSI ID number. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 12
Setting the terminator switch . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 12
Setting the select switch . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 13
Connecting the scanner . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 14
Power-on sequence. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 15
Power-off sequence . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 15
Installing EPSON TWAIN HS. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 16
For Windows Millennium Edition users . . . . . . . . . . . . . . . . . . . . . . . . . 16
For Windows 98 and 2000 users . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 18
For Windows 95 and NT 4.0 users. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 19
Calibrating Your Screen . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 21
Using the Online Manuals . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 22
Installing Adobe Acrobat Reader. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 23
Accessing the online manuals . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 24
Customer Support . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 24

Epson GT-30000 Specifications

Power

voltage	AC 100V-120V, 220V-240V
frequency	50-60Hz
power consumption operating without ADF	65W
power consumption operating with ADF	90W
power consumption standby without optional unit	12W

Operating Environment

temperature operating	41ºF to 95ºF (5ºC to 35ºC)
humidity operating	10% to 80% (no condensation)
humidity storage	10% to 85% (no condensation)

Scanning Specifications

optical resolution	600 x 1200 dpi with Micro Step Drive™ technology
maximum resolution	9600 x 9600 dpi with interpolation
effective pixels	7020 x 10200 pixels (600 dpi)
color depth internal	36 bits per pixel
color depth external	24 bits per pixel (selectable)
grayscale depth internal/external	12 bits per pixel
grayscale depth external	8 bits per pixel
scanning speed at 1600 dpi, draft mode, color	0.79 msec/line (approx.)
scanning speed at 1600 dpi, draft mode, grayscale	0.39 msec/line (approx.)
scanning speed at 1600 dpi, draft mode, art	0.39 msec/line (approx.)

Weight and Dimensions

maximum read area	11.7" x 17.0" (297mm x 432mm)
width	25.9" (658mm)
depth	19.2" (488mm)
height	10.0" (254mm)
weight	66 lb (37.5 kg approx.)
