Epson L800 Service Manual

L800/L801 Revision A
Appendix Fatal Error Code 104
Confidential
4.3.2 Fatal Error Code
This section describes the fatal error code and the possible cause for this
product.
Table 4-3. Fatal Error List
Error type
Error
code
Error name Possible cause
DC motor
error
01H CR PID excess speed error
• CR Encoder failure (contaminated/detached
scale, Encoder Board failure)
• Motor driver failure (Main Board failure)
• Carriage overload (paper jam/foreign object)
• Cable disconnection
02H
CR load positioning lock
error
• CR Encoder failure (contaminated/detached
scale, Encoder Board failure)
• CR Motor failure
• Carriage overload (paper jam/foreign object)
• Cable disconnection
08H CR PID reverse error
• CR Encoder failure (contaminated/detached
scale, Encoder Board failure)
• Tooth skip of the CR Timing Belt
• Improper tension of the CR Timing Belt
• Carriage overload (paper jam/foreign object)
0AH
CR load positioning
cumulative movement
distance error
• CR Motor failure
• Motor driver failure (Main Board failure)
0BH
CR load positioning excess
speed error
• CR Encoder failure (contaminated/detached
scale, Encoder Board failure)
• Motor driver failure (Main Board failure)
• Carriage overload (paper jam/foreign object)
• Cable disconnection
0CH CR PID lock error
• CR Encoder failure (contaminated/detached
scale, Encoder Board failure)
• CR Motor failure
• Carriage overload (paper jam/foreign object)
• Cable disconnection
0DH CR PID aveTi max error
• CR Motor failure
• Motor driver failure (Main Board failure)
• Improper tension of the CR Timing Belt
• Carriage overload (paper jam/foreign object)
DC motor
error
FBH
PF PID acceleration lock
error
• PF Motor failure
• PF drive mechanism overload (paper jam/
foreign object)
FEH PF PID excess speed error • PF Encoder failure (contaminated/detached
scale, Encoder Board failure)
• Motor driver failure (Main Board failure)
• PF drive mechanism overload
(paper jam/foreign object)
• Cable disconnection
FCH PF BS excess speed error
FAH
PF excess measurement
error
• PF drive mechanism overload (paper jam/
foreign object)
EFH
PF BS control positioning
error
• PF Motor failure
• Motor driver failure (Main Board failure)
F0H
PF BS control DTY_max
error
• PF Motor failure
• PF drive mechanism overload (paper jam/
foreign object)
APG motor
error
70H
APG error
(normal drive error)
• Foreign object
• APG Unit failure (incorrect reassembling)
• APG Sensor failure
• Cable disconnection
71H
APG home position
seeking error
72H
APG drive error
(by command)
---*
Motor
drive time
error
D1H CR (PID) driving time error
• Main Board failure
D2H
CR (load positioning)
driving time error
D3H PF (PID) driving time error
D4H PF (BS) driving time error
Command
error
30H
EEPROM verify error
(by command)
---*
Table 4-3. Fatal Error List
Error type
Error
code
Error name Possible cause

Epson L800 Specifications

General

Print technology	Inkjet
Maximum resolution	5760 x 1440 DPI
Print speed (10x15 cm)	12 s
Print speed (black, draft quality, A4/US Letter)	37 ppm
Print speed (color, draft quality, A4/US Letter)	38 ppm
Printing sizes	10 x 15 cm
Maximum print size	216 x 356 mm
ISO A-series sizes (A0...A9)	A4, A6
Photo paper sizes (imperial)	4x6, 8x10 \
Total input capacity	120 sheets
Product color	Black
Built-in display	No
Market positioning	Home & office
Number of printing colors	6
USB port	Yes
Direct printing	-
USB 2.0 ports quantity	1
AC input voltage	100 - 120 V
AC input frequency	50 - 60 Hz
Power consumption (printing)	13 W
Sustainability certificates	ENERGY STAR
Operating temperature (T-T)	5 - 40 °C
Operating relative humidity (H-H)	20 - 80 %
Connectivity technology	Wired
Mac operating systems supported	Mac OS X 10.5 Leopard, Mac OS X 10.6 Snow Leopard, Mac OS X 10.7 Lion, Mac OS X 10.8 Mountain Lion
Windows operating systems supported	Windows 7 Home Basic, Windows 7 Home Premium, Windows 7 Professional, Windows 7 Starter, Windows 7 Ultimate, Windows Vista Business, Windows Vista Enterprise, Windows Vista Home Basic, Windows Vista Home Premium, Windows Vista Ultimate, Windows XP Home, Windows XP Professional, Windows XP Professional x64

Weight and Dimensions

Depth	289 mm
Width	537 mm
Height	188 mm
